Liquids: chemicals, ultrapure water (do not use muddy liquids) Chemicals, D. IWater(Don’t use the slurry)
Working pressure: 0-0.5Mpa
Pneumatic diaphragm valve actuator control pressure: 0.5Mpa control port: Rp 1/8
Back pressure: 0-0.5Mpa
Working temperature: normal temperature 0-100℃, high temperature 0-130℃
Material: Main body: PFA nut: PFA base and actuator: PVDF diaphragm: PTFE
Precautions: According to the precautions of internal chemical substances, due to changes in product materials and specifications, please confirm whether it is suitable before use. Do not use it for special gases
(Such as: N2. AIR, etc.), mostly used for liquids. Due to the characteristics of the fuselage material, it may be damaged due to vibration. Check the input and output directions when setting up.
Connection method: flared type
Material: Body: PFA sealing ring: PTF
Working temperature: 17℃-100℃
Pressure range: 913mbar-7bar
Flared type
Size | Diameter | L | H |
1/4" | φ3.1 | 78.7 | 86.65 |
3/8" | φ6.5 | 80.1 | 86.26 |
1/2" | φ9.9 | 85.1 | 87.7 |
